Explorer is a versatile solar lighting tower specifically designed to provide emergency lighting.
Ideal for use in Large construction projects, Mining operations, Maintenance & Repair, Accident Handling, Flood Prevention & Rescue, Disaster Relief etc. It's fitted with high-performance, energy-efficient LED foodlights, which canmake the most of the battery pack and the whole system. Manual or automatic adjustment of LED floodlights are both available. 360° rotation offers greaterlighting coverage.
Explorer is a smart mobile solar lighting tower.
It has a LCD control panel, and also works by remote control, as well as background control on a PC. The mast can be raised or lowered steplessly, and rotated horizontally and vertically by all-electric control, and remotely monitored, controlled, alarmed on computers.
Explorer has great advantages in terms of energy storage and power consumption.
It can power the LED floodlights up to 24 hours on a single full charge, and recharge with mains in an emergency. it supports 100-220Vac /50-60Hz output, and uses deep cycle gel battery, reliable and durable.
|
T500-6M |
T500-9M |
| Starter |
Starter |
| General |
System voltage |
DC 24V |
DC 24V |
| PV Controller |
MPPT 40A, 95% |
MPPT 40A, 95% |
| IP rating |
IP65 |
IP65 |
| Control |
Remote control / LCD panel |
Remote control / LCD panel |
| Battery charging |
Solar |
Solar |
| Charging time |
8 hours |
10 hours |
| Running time |
35 hours |
24 hours |
| Illuminated area @ 6m |
1000-1200 m2 |
1200-1500 m2 |
| Warranty |
2 years |
2 years |
| LED Luminaire |
Rotation / Tilt |
Fixed |
Fixed |
| Beam angle |
80° |
80° |
| Wattage |
4 x 50W |
4 x 100W |
| Light output |
47000 lm |
94000 lm |
| Warranty |
5 years |
5 years |
| Certification |
3C、CE、UL、TUV |
3C、CE、UL、TUV |
| Solar Panel |
Brand name |
LONGi |
LONGi |
| Type |
Monocrystalline silicon |
Monocrystalline silicon |
| Wattage |
4x230W |
4x230W |
| Efficiency |
21.70% |
21.70% |
| Lifespan |
25 years |
25 years |
| Certification |
CSA、TUV、CE、UL |
CSA、TUV、CE、UL |
| Battery |
Type |
Gel Battery |
Gel Battery |
| Capacity |
4x 150 AH 12V |
4x 200 AH 12V |
| Certification |
UL、CE |
UL、CE |
| Mast |
Height |
2.5－6 m, retractable |
2.5－6 m, retractable |
| Control |
Electric |
Electric |
| Wind resistance |
Level 8 |
Level 8 |
| Material |
Hot-Dip Galvanized Steel |
Hot-Dip Galvanized Steel |
| Packing |
Equipment dimensions |
1000*1000*7000 mm |
1000*1000*7000 mm |
| Packing dimensions |
1000*1000*2200 mm |
1000*1000*2200 mm |
| Weight |
750 kg |
750 kg |
| Container loading |
|
|
|
